Technical Specifications
• Type of Pump: Gear Pump
• Max. Flow rate: 20 LPM & 40 LPM
• Operating Pressure: 4 to 5 Bar
• Permiss Suction Pressure: -0.4 bar..... +0.6 bar
• Viscosity Range: 15 to 200 mm²/sec
• Permiss Operating Fluid: Mineral Oil (Other fluid on request)
• Fluid Temp: 25.........80°C
• Ambient Temp: 25.........40°C
• Seal: NBR
• Length Of Electric Cable: 6 Mtrs.
• Length Of Hose: 3 Mtrs
• Hose Connection: To suit ¾”/ 1” BSP connection
